PVC Foam Core Density Chart Guide

A truck body manufacturer in southern Germany lost €220,000 on a single bad density call last year. They specified 60 kg/m³ pvc foam core for refrigerated van panels chasing a 12% weight reduction over their previous build. Six months into service, those panels started delaminating. The low-density foam had soaked 35% more resin during layup than their engineers calculated, pushing the actual finished panel weight past what a 100 kg/m³ core would have delivered. The fuel efficiency gains they promised their customer never materialized. The warranty claim ate their margin on that entire contract.

We pulled three years of our own lab test data across density grades from 45 to 250 kg/m³ and cross-referenced it against what vehicle OEMs actually specify in production builds. This guide maps every grade to its compressive strength, shear modulus, and tensile performance — then shows you the resin uptake numbers most suppliers leave off their datasheets. You will see exactly where cross-linking justifies the cost premium for dynamic loads, and where a lower density grade saves weight without sacrificing panel stiffness. One chart. No marketing spin. Just the numbers you need to spec the right core the first time.

What Is PVC Foam Core

PVC foam core is a rigid, closed-cell thermoplastic used as a structural core in composite panels. Its density range of 45–250 kg/m³ dictates stiffness, strength, and resin uptake.

Closed-Cell Structural Foam Definition

PVC foam core is a lightweight, rigid material utilized as the load-bearing center layer in sandwich panels. Its closed-cell structure is critical for vehicle and marine applications, ensuring water absorption remains below 1% to prevent core rot and maintain thermal insulation efficiency. We produce this material in five distinct grades ranging from ultra-low density at 45 kg/m³ to ultra-high density at 250 kg/m³, allowing engineers to precisely balance weight reduction against structural requirements.

Cross-Linked vs. Non-Cross-Linked Types

The chemical structure of the foam determines its long-term durability under dynamic loads. You must differentiate between linear (non-cross-linked) and cross-linked PVC when specifying for high-stress vehicle components. Cross-linked variants provide superior performance in fatigue scenarios, which is essential for commercial vehicles enduring constant road vibration over a 10-year lifespan.

• Compressive Modulus: Cross-linked PVC offers 20–35% higher compressive modulus compared to non-cross-linked types at the same density grade.
• Fatigue Retention: After 10⁶ load cycles, cross-linked foam retains 85–90% of its shear modulus, whereas non-cross-linked foam typically drops to 70–75%.
• Processing Stability: Cross-linked foam resists the high exotherm temperatures generated during resin curing better than linear alternatives.

Why Density Governs Every Other Property

Density is the primary variable controlling mechanical performance and total assembly cost. While lower density grades save nominal weight, they significantly increase resin consumption during the lamination process. Our internal testing confirms that low-density foams (60–80 kg/m³) absorb 30–40% more resin by volume than 130 kg/m³ foams. This hidden weight gain often erodes the intended fuel efficiency savings in vehicle design. Selecting the correct density grade involves calculating the trade-off between core weight and the stiffness required to prevent panel deflection under specific load cases.

PVC Foam Core Density Chart

PVC foam core spans 45–250 kg/m³ across five density grades. Specifying the right grade requires balancing static mechanical properties against two hidden variables: resin uptake weight gain and cross-linking fatigue life.

Density Grade Classification

Our PVC foam core is produced in five distinct density bands, each engineered for a different structural tier. Selecting the correct band is the first and most consequential decision in sandwich panel design for vehicle bodies.

• Ultra-Low (45 kg/m³): Non-structural thermal break and lightweight fill applications. Minimal compressive capacity.
• Low (60–80 kg/m³): Light-duty insulation panels, refrigerated truck sidewalls where dead-weight savings take priority over load-bearing. Resin uptake adds 8–15% hidden weight at these grades.
• Medium (100 kg/m³): The general-purpose structural benchmark for RV sandwich panels and mid-range truck bodies. Compressive strength reaches 1.0–1.4 MPa.
• High (130 kg/m³): Heavy-duty structural panels, flooring substrates, and crash-zone energy absorbers. Optimal balance of mechanical performance and resin uptake efficiency.
• Ultra-High (200–250 kg/m³): Maximum stiffness and load transfer. Used in wheel-arch reinforcements, structural bulkheads, and high-impact zones.

Standard production thicknesses cover 3, 5, 10, 15, 19, 25, 30, and 50 mm. We CNC-cut all sheets to ±0.3 mm tolerance to prevent the cumulative gap cascade that derails multi-panel vehicle assembly lines.

Compressive Strength by Density

Compressive modulus scales non-linearly with density. Our test data across the five grades shows the following ranges measured per ISO 844 at 23 °C.

• 60 kg/m³: Compressive modulus approximately 30 MPa. Sufficient for insulated wall panels with no point loads.
• 80 kg/m³: Compressive modulus approximately 50 MPa. Common in refrigerated truck sidewalls where racking loads are moderate.
• 100 kg/m³: Compressive modulus approximately 80 MPa, compressive strength 1.0–1.4 MPa. The default choice for RV roof and floor sandwich panels.
• 130 kg/m³: Compressive modulus approximately 130 MPa. Recommended for commercial truck body floors subject to forklift or pallet-jack loading.
• 200 kg/m³: Compressive modulus approximately 300 MPa. Reserved for high-stress attachment points and structural inserts.

Cross-linked grades deliver 20–35% higher compressive modulus versus non-cross-linked at the same nominal density. For static panels this difference is marginal. For panels absorbing a decade of road vibration, it becomes the deciding factor in fatigue life.

Shear Strength and Shear Modulus Data

Core shear transfer is what allows a sandwich panel to act as a unified structural element rather than two separate skins. Under-specifying shear properties leads to panel delamination under racking or diagonal loads—particularly in vehicle bodies subjected to road-induced torsion.

• 60 kg/m³: Shear modulus approximately 12 MPa, shear strength approximately 0.5 MPa.
• 80 kg/m³: Shear modulus approximately 20 MPa, shear strength approximately 0.6 MPa.
• 100 kg/m³: Shear modulus approximately 40 MPa, shear strength 0.75–1.10 MPa.
• 130 kg/m³: Shear modulus approximately 60 MPa, shear strength approximately 1.3 MPa.
• 200 kg/m³: Shear modulus approximately 120 MPa, shear strength approximately 2.0 MPa.

Our internal fatigue cycling tests show cross-linked PVC retains 85–90% of its original shear modulus after 10⁶ load cycles. Non-cross-linked equivalents drop to 70–75% retention over the same cycle count. For truck bodies and RVs expected to endure 10+ years of continuous road vibration, this 15-point spread is the difference between a panel that ages gracefully and one that develops progressive skin-core debonding in service.

Tensile Strength Reference Values

Tensile strength perpendicular to the panel plane governs resistance to skin peel-off under impact or overpressure conditions. It is the least forgiving mechanical property—once the core tears in tension, the sandwich structure loses nearly all post-failure integrity.

• 60 kg/m³: Tensile strength approximately 0.8 MPa.
• 80 kg/m³: Tensile strength approximately 1.0 MPa.
• 100 kg/m³: Tensile strength 1.2–1.6 MPa.
• 130 kg/m³: Tensile strength approximately 2.0 MPa.
• 200 kg/m³: Tensile strength approximately 3.5 MPa.

A practical specification note: an 80 kg/m³ core saves approximately 12% dead-weight versus a 130 kg/m³ core in equivalent panel construction. However, the 80 kg/m³ grade absorbs 30–40% more resin by volume during lamination, partially erasing the nominal weight saving and adding material cost. We recommend running a resin-uptake-adjusted weight calculation before finalizing any density selection for vehicle production programs.

Cross-Linked vs Non-Cross-Linked PVC

Cross-linked PVC delivers 20–35% higher compressive modulus and drastically better fatigue life than non-cross-linked alternatives, making it mandatory for structural vehicle panels subjected to high-temp cures and dynamic road loads.

Property Comparison: Cross-Linked vs Non-Cross-Linked PVC

The fundamental difference between these two foam cores comes down to the cellular structure. Cross-linking the polymer matrix creates a rigid, interlinked network. This molecular shift directly impacts how the core handles compressive loads, heat, and long-term vibration. When we evaluate materials for specialized vehicle sandwich panels, the divergence in physical properties is immediate.

• Compressive Modulus: Cross-linked PVC offers a 20–35% higher compressive modulus compared to non-cross-linked foam at the exact same density grade.
• Fatigue Life: Our test data shows cross-linked PVC retains 85–90% of its shear modulus after 10⁶ cycles. Non-cross-linked grades drop to 70–75% under identical dynamic loading.
• Heat Distortion Temperature (HDT): Cross-linked structures withstand significantly higher curing temperatures without cell collapse or outgassing.
• Toughness: Non-cross-linked PVC is generally more ductile and forgiving under sudden impact, whereas cross-linked PVC behaves with higher stiffness but lower overall elongation.
• Material Cost: Expect a higher raw material cost for cross-linked grades due to the additional chemical processing required to initiate the cross-linking reaction.

The Case for Cross-Linked PVC in Vacuum Infusion and High-Temp Cures

If your manufacturing process involves elevated curing temperatures—such as using prepreg resins or fast-cure epoxy systems—cross-linked PVC is the engineering requirement. Non-cross-linked foams can soften or outgas when exposed to high exothermic reactions, leading to blown cells and internal delamination. Cross-linked foam remains dimensionally stable, holding the tight tolerances required for precision CNC-cut vehicle panels.

During vacuum infusion processing, cross-linked PVC generally exhibits lower resin uptake. While lower density grades can absorb 8–15% hidden resin weight, the tighter cell structure of cross-linked foam prevents excessive resin consumption, protecting your target fuel efficiency margins. For truck bodies and RVs absorbing constant road vibration over a 10-year lifespan, the combination of high heat resistance and superior fatigue retention makes cross-linked PVC the standard specification for heavy-duty composite design.

Density vs Resin Uptake: The Hidden Cost Factor

Specifying a low-density PVC foam core to hit vehicle weight targets often backfires. The resin it soaks up during lamination adds 8–15% in hidden weight, erasing fuel efficiency gains before the panel leaves production.

Why Lower Density Foams Secretly Cost More in Production

The logic seems sound on paper: specify 60 kg/m³ PVC foam instead of 130 kg/m³ and you save roughly 70 kg per cubic meter of core volume. For a specialized vehicle manufacturer trying to hit aggressive fuel economy targets, that number looks compelling. But our production data tells a different story once the lamination stage begins.

Lower density PVC foam has a more open cell structure and larger cell walls that act as capillary channels during hand lay-up or vacuum infusion. The foam literally drinks resin. Our measurements show that 60 kg/m³ foam can absorb 30–40% more resin by volume than 130 kg/m³ foam under identical lamination conditions. That extra resin adds weight you never accounted for in your CAD model—and it adds material cost you never budgeted in your BOM.

This is the single most overlooked cost factor in composite vehicle design. Engineers compare nominal density on datasheets but rarely quantify resin uptake differentials. The result: a panel that was supposed to weigh 12 kg/m² comes out at 13.5–13.8 kg/m², and suddenly the vehicle is over its target axle load.

Approximate Resin Absorption by Density Grade

The table below presents resin uptake data collected from our production runs across standard PVC foam density grades. Values represent approximate resin absorption during vacuum bag lamination at 0.7 bar vacuum pressure using standard polyester resin. Your actual numbers will vary with resin viscosity, laminate schedule, and cure cycle, but the proportional relationship between density and uptake holds consistent.

The engineering implication is straightforward. When you specify 60 kg/m³ core for a truck body panel at 25 mm thickness, you are absorbing roughly 3.75–4.63 kg/m² of resin into the foam alone. Step up to 100 kg/m³ and that drops to 2.13–2.63 kg/m². Over a full vehicle body with 50–80 m² of panel area, the resin weight penalty for choosing ultra-low density can exceed 100 kg—completely negating the core weight savings you designed for.

We recommend running a true-cost comparison before finalizing density selection. Calculate the finished panel weight including resin uptake, not just the nominal foam weight. For most RV and commercial vehicle applications, 80–100 kg/m³ hits the practical sweet spot: low enough resin absorption to keep finished panel weight predictable, with sufficient mechanical properties for structural sandwich panels under dynamic road loads.

Explore Our Foam Core Sandwich Panels.

Browse our complete range of lightweight, foam-based composite panels built with various core materials for demanding structural applications.

Explore Full Product Range →

PVC Foam vs Alternative Core Materials

PVC, PET, and honeycomb each solve a different structural problem. We laid out the mechanical trade-offs below so your CAD model reflects reality, not marketing.

PVC vs PET Foam (Strength-to-Weight)

PET foam has gained traction in structural composites due to its recyclability and competitive pricing at higher densities. However, when you normalize for equal density, PVC foam core delivers higher shear modulus and better fatigue retention. Our data at 100 kg/m³ shows PVC achieves compressive strength of 1.0–1.4 MPa and tensile strength of 1.2–1.6 MPa. PET at the same nominal density typically falls 10–15% lower on shear modulus in standardized ASTM C393 flexural testing. For vehicle OEMs chasing weight reduction % targets, that gap compounds across an entire truck body or RV shell.

The critical distinction most datasheets bury is resin uptake. Within PVC foam core grades alone, low-density foam at 60 kg/m³ can absorb 30–40% more resin by volume than a 130 kg/m³ grade. This hidden weight directly erodes the fuel efficiency gains you thought you were getting by specifying a lighter core. PET foam cores, with their generally more open cell structure at lower densities, can exhibit even higher resin consumption than PVC at equivalent weight grades. Factor resin mass into your bill of materials before committing to a density specification.

Fatigue life is where PVC separates from PET in dynamic-load applications. Cross-linked PVC retains 85–90% of its shear modulus after 10⁶ cycles, compared to 70–75% for non-cross-linked PVC. Within the PVC foam family itself, cross-linked grades offer a 20–35% higher compressive modulus versus non-cross-linked options at the exact same density grade. For truck bodies and RVs absorbing constant road vibration over a 10-year service life, that fatigue retention gap is the difference between a warranty claim and a satisfied fleet operator.

PVC vs Honeycomb Core (Stiffness Trade-Offs)

Honeycomb cores—whether aluminum or GRP/FRP—win on raw stiffness-to-weight ratio in flat panel applications. A honeycomb sandwich panel at 80 kg/m³ equivalent will outperform a PVC foam core panel of the same weight in three-point bending stiffness. But that advantage comes with three structural compromises that vehicle engineers must weigh carefully before signing off on a bill of materials.

• Thermal insulation: PVC foam core panels provide continuous thermal resistance critical for refrigerated truck bodies. Honeycomb cells create thermal bridges that force you to add separate insulation layers, increasing total assembly weight and labor cost.
• Isotropic vs anisotropic behavior: Closed-cell PVC foam provides uniform mechanical properties in all directions. Honeycomb cores resist shear primarily in the T-direction, meaning out-of-plane loads—common in vehicle floors and bulkheads—require careful core orientation planning.
• Compression uniformity: Honeycomb crushes irreversibly once its cell walls buckle past yield. PVC foam compressive modulus ranges from 30 MPa at 60 kg/m³ to 300 MPa at 200 kg/m³, with ductile recovery that survives localized impact without catastrophic panel failure.

Our engineering recommendation is straightforward. If your application demands maximum panel stiffness with no thermal requirement—such as structural cargo container walls or flatbed decking—GRP honeycomb delivers a clear weight advantage. For any application involving temperature control, moisture exposure, or multi-directional dynamic loads, PVC foam core provides a more forgiving and thermally complete structural solution. Many specialized vehicle manufacturers we supply ultimately specify PVC foam for insulated compartments and honeycomb for non-insulated structural partitions within the same vehicle platform, optimizing each zone for its dominant performance requirement rather than defaulting to a single core type across the entire build.

Selecting the Right Density for Vehicle Applications

Density selection dictates the weight-to-stiffness ratio and hidden resin costs in vehicle assemblies. Specifying the correct grade prevents structural failures and fuel efficiency losses.

RV Wall and Roof Panels (60–80 kg/m³)

For recreational vehicles, minimizing curb weight is the primary engineering target to maintain drivability and hit fuel efficiency marks. Specifying a PVC foam core in the 60–80 kg/m³ range provides adequate stiffness for large wall and roof spans without adding unnecessary mass. Our testing shows a compressive modulus starting at 30 MPa for 60 kg/m³ grades, which handles standard wind loads effectively.

Engineers must account for resin uptake when calculating the final assembly weight. Lower density foam in the 60–80 kg/m³ range can absorb 30 to 40 percent more resin by volume than a 130 kg/m³ core. This adds an 8 to 15 percent hidden weight penalty that often wipes out the nominal weight savings you initially calculated on the bill of materials.

Truck Body Panels (100–130 kg/m³)

Commercial truck bodies experience severe dynamic loads, cargo impacts, and constant road vibration over a 10-year lifespan. A PVC foam core density between 100 and 130 kg/m³ delivers the necessary shear and compressive resistance for these high-stress environments. At 100 kg/m³, our material tests yield a compressive strength of 1.0 to 1.4 MPa and a shear strength of 0.75 to 1.10 MPa.

Because truck trailers demand high fatigue resistance, cross-linked PVC is strongly recommended for these applications.

• Dynamic Load Retention: Cross-linked PVC retains 85 to 90 percent of its shear modulus after 10⁶ cycles.
• Non-Cross-Linked Degradation: Standard variants drop to 70 to 75 percent retention under identical fatigue testing.
• Assembly Tolerance: We machine these cores to ±0.3mm precision, eliminating the cumulative gaps that halt production lines.

Marine Hull and Deck (80–130 kg/m³)

Marine hulls and decks demand a core material that resists water ingress while surviving constant slamming forces. Operating within the 80 to 130 kg/m³ density range provides the optimal balance for marine composite structures. The closed-cell architecture of our PVC foam maintains less than 1 percent water absorption, preventing delamination and structural rot in GRP and FRP laminates.

When specifying for high-impact deck areas or hull bottoms, cross-linked PVC yields a 20 to 35 percent higher compressive modulus compared to non-cross-linked options at the exact same density. This provides superior energy absorption without forcing you to step up to a heavier core material that would compromise the vessel’s stability or payload capacity.

Thickness Options and Tolerance Impact on Assembly

In vehicle assembly, specifying panel thickness without enforcing a strict tolerance invites cascading gaps that will halt your production line. We CNC-cut our PVC foam core to a guaranteed ±0.3mm tolerance to ensure seamless multi-panel mating without manual shimming.

Standard Thickness Range (3mm–50mm)

Our structural PVC foam core is manufactured in a standard thickness range from 3mm to 50mm, accommodating everything from lightweight interior RV liners to thick, heavy-duty refrigerated truck body panels. Selecting the correct thickness depends directly on the required flexural modulus and the unsupported span of the sandwich structure in your CAD model. We maintain a consistent density profile across this entire range, ensuring that the core mechanical properties at a given density remain identical whether you specify a 5mm or a 25mm sheet.

• Standard Available Profiles: 3mm, 5mm, 10mm, 15mm, 19mm, 25mm, 30mm, and 50mm.

Impact of ±0.3mm Tolerance Deviation on Assembly Gaps

A ±0.3mm thickness deviation might look negligible on a raw material datasheet, but it creates immediate mechanical bottlenecks during multi-panel vehicle assembly. When joining several panels along a 2.4m truck sidewall, an uncontrolled thickness variance results in cumulative gaps and misaligned joint surfaces at the structural bonding points. Line workers are then forced to manually shim the gaps or rework the adhesives, which drastically increases your assembly cycle time and drives up the defect rate per batch.

Importance of Precision-Cut Materials

Controlling this variance requires precision-cut materials rather than raw, untrimmed foam blocks that leave tolerance management to the vehicle OEM. We utilize CNC custom cutting to hold our PVC foam core to a strict ±0.3mm thickness tolerance across the entire sheet surface. This precision ensures that every panel drops directly into your vehicle chassis jig without manual intervention, protecting your production throughput and eliminating the hidden labor costs associated with poor material tolerances.

Conclusion

If you’re spec’ing panels for truck bodies or RVs, go cross-linked PVC at 80–100 kg/m³ and stop overthinking it. Drop below 80 kg/m³ to chase weight savings and you’ll eat 30–40% more resin by volume—that hidden weight erases your nominal density advantage and kills your fuel efficiency targets. We watched two OEMs learn this the hard way in 2026, both forced to requalify materials mid-production.

Before you commit to a grade, ask your supplier for two things: a resin uptake comparison between 80 and 130 kg/m³ at your target thickness, and a fatigue test report showing shear modulus retention after 10⁶ cycles. Those two numbers will confirm whether you’re actually saving weight or just moving cost from the bill of materials to the assembly line.
