RaxPanel stainless steel sandwich panels offer excellent fireproof performance, thermal insulation, and sound absorption. They are naturally durable and stable over a building's lifetime, unaffected by temperature or humidity changes, ensuring energy savings and a comfortable environment. The panels are non-combustible, contribute to fire safety, and provide real noise reduction. Installation is fast, shortening construction periods by over 40%, and the product guarantees a life time of 25 years.

RaxPanel stainless steel sandwich panels are rated non-combustible (Class A1) and offer fire resistance of up to EI 90 / E 120 for certain thicknesses. They do not contribute to fire spread, shrink, stretch, or deform when exposed to fire, and produce no smoke or burning droplets. The panels can resist high temperatures, with some configurations providing up to 120 minutes of fire resistance.

RaxPanel stainless steel sandwich panels are produced in accordance with building layout drawings for fast and flexible installation. They can be installed vertically or horizontally on single- or multi-span structures, often using hidden joints for an aesthetic finish. The construction period can be shortened by more than 40%, making them ideal for prefabricated buildings. Proper storage and handling are recommended to avoid exposure to weather.

RaxPanel stainless steel sandwich panels are available in thicknesses of 50mm, 75mm, 100mm, 125mm, 150mm, and up to 200mm. The effective width is typically 1000mm (with options for 950mm or 1150mm), and length is customized as required, though usually limited to less than 12000mm for transportation. Steel thickness options range from 0.3mm to 1.0mm.

RaxPanel stainless steel sandwich panels are applied as external walls, internal division walls, ceilings, and for object insulation. They are ideal for industrial buildings, warehouses, logistic centers, commercial offices, food industry facilities, agricultural objects, sports halls, clean rooms, and residential buildings. Their fireproof and acoustic properties make them suitable for environments with high safety and noise reduction requirements.

RaxPanel stainless steel sandwich panels have a thermal conductivity (λ) of 0.043 W/mK, providing excellent thermal insulation. Acoustic insulation is up to 27 dB for standard configurations, with noise reduction coefficients (NRC) ranging from 0.80 to 0.95. The panels help maintain stable indoor temperatures and significantly reduce external noise, enhancing comfort and energy efficiency.

RaxPanel stainless steel sandwich panels are produced under strict quality management systems, ensuring a guaranteed lifespan of 25 years. They require minimal maintenance; however, for long-term storage, panels should be kept indoors or, if outdoors, stacked clear of the ground and covered with a weather-proof sheet. Regular inspections for damage and cleaning with mild soap and water are recommended.

We work closely with manufacturers throughout the product innovation process, from initial preparation and testing stages to the creation of tailored solutions. Our panels are produced in full accordance with building layout drawings, ensuring a customized product for your specific process. With production capabilities including thicknesses from 50mm to 200mm, various steel thickness options (0.3mm-1.0mm), and multiple facing materials (galvanized, aluminum, stainless steel), we can accommodate deep customization requirements. The sophisticated production process ensures high-density rock wool insulation with strong adhesion between the core and metal plates, providing excellent stiffness and performance for your integration needs.

We provide comprehensive technical documentation including detailed technical data sheets, performance test reports, and material samples. Our products come with all quality and fire resistance certificates, with fire resistance ratings of EI 90 / E 120 and corrosion resistance classifications of C1, C2, C3. Technical parameters include thermal conductivity of 0.043 W/mK, acoustic insulation of 27 dB, and panel areal weights ranging from 15.50 to 36.50 kg/m² depending on thickness. The rock wool core material density of 100-120 kg/m³ ensures consistent performance, and we offer detailed specifications for thermal transmittance U-values across different thickness options to meet your project's compliance requirements.

With 20+ years of manufacturing experience and a daily output of 1500+ m², we ensure reliable supply chain stability for bulk orders. We maintain stock of standardized products and samples in multiple colors, and our production process follows international quality management systems to guarantee consistent quality. The automatic production machine operates at constant temperature, and all raw materials and processes are in strict accordance with quality standards, ensuring product stability and a guaranteed lifetime of 25 years. We offer just-in-time delivery capabilities and can accommodate customized production schedules to meet your inventory turnover needs while maintaining favorable pricing for bulk orders.
